Haas VF-5SS/40 4-Axis CNC Vertical Machining Center, 15,000 rpm Spindle, New 2015
Have one to sell?
1 available
Haas VF-5SS/40 4-Axis CNC Vertical Machining Center, -
15,000 rpm Spindle
- Side Mount tool changer - 30 tools
- multi Auger Chip removal
750 MB expanded memory
Ethernet interface
- Programmable coolant nozzle
- High Speed Machining
- Remote Jog handle with touchscreen display
- rigid Tapping
- Chip Strainer
- Wireless Intuitive probing system
New 2015
Specs:
X Axis Travel: 50"
Y Axis Travel: 26"
Z Axis Travel: 25"
Rapid Rate X Axis: 710 IPM
Rapid Rate Y Axis: 710 IPM
Rapid Rate Z Axis: 710 IPM
Max Table Load: 4,000 LBS
Spindle Motor: 30 HP
Spindle Speed: 15,000 RPM
Spindle Taper: 40 BT
Tool Changer: 24 ATC
Max Cutting: 500 ipm
Max Thrust X: 2550 lbf
Max Thrust Y: 4100 lbf
Max Thrust Z: 4100 lbf
Max Tool Diameter: 3.5"
Max Tool Weight: 12 lb
Tool-to-Tool (avg): 4.2 s
Chip-to-Chip (avg): 4.5 s
Table Size: 54" x 24"
Haas CNC Controls
15,000 rpm Spindle
- Side Mount tool changer - 24 tools
- multi Auger Chip removal
750 MB expanded memory
Ethernet interface
- Programmable coolant nozzle
- High Speed Machining
- Remote Jog handle with touchscreen display
- rigid Tapping
- Chip Strainer
- Wireless Intuitive probing system
New 2015
