OKUMA V40R CNC 3-AXIS VERTICAL LATHE, NEW 2012, LIVE TOOLING, C-AXIS,
12" 3-JAW CHUCK, FANUC 31i-A CNC CONTROL
• Max swing diameter: 19.69"
• Max turning length:17.72"
• Max chuck size: 17.72"
• Max turning diameter: 15.75"
• Max workpiece weight: 660 lbs.
• X axis Travel: 10.43"
• Z axis Travel: 17.72"
• Spindle Speed: 25 - 2,500 RPM
• Turret Type: V12
• Type of Nose: A2-8
• 12 Position turret with 6 Live tooling stations
• 5HP 2000rpm spindle
•
• Fanuc 31i-a Control
• Live tooling stations 6
• C-axis
• 12" 3-Jaw Chuck
• Coolant System
• Chip Conveyor
• 1 radial live tool and 1 axial live tool
