2011 HAAS GR-712 CNC 3-AXIS GANTRY ROUTER, 72" x 144" TABLE, COOLANT
Have one to sell?
1 available
Explore large-scale precision with the HAAS GR-712 CNC Router, 2011 model. Experience reliable performance with a 7'x12' table, 8100 RPM spindle, &10-slot ATC. Ideal for a variety of applications. Ready to enhance your production floor.
Travels:
X Axis 145"
Y Axis 85"
Z Axis 11"
OPTIONAL 24" Z-AXIS EXTENTION
Spindle Nose to Table (Max.) 13.5"
Spindle Nose to Table (Min.) 2.5"
Table:
Length 144"
Width 72"
Thickness 1"
Between Columns 86"
Max. weight on table (evenly distributed) 6000 lbs
Spindle:
Max. Rating 15 HP
Max. Speed 8100 RPM
Max. Torque 17 ft-lb @ 4600 RPM
Drive System (Direct Speed) Belt Drive
Taper CT 40
FeedRates:
Rapids on X 800 in/min
Rapids on Y 2100 in/min
Rapids on Z 1100 in/min
Max. Cutting 800 in/min
Axis Motors:
Max. Thrust X 2520 Lb
Max. Thrust Y 1020 Lb
Max. Thrust Z 2050 Lb
Tool Changer:
Type Carousel
Capacity 10
Max. Tool Diameter (Full) 3.5"
Max. Tool Weight 12 Lb
General:
Air required 4 scfm, 100PSI
Coolant Capacity
Haas CNC Controls
7'x12" Aluminum Table
8100 RPM 40 Taper Spindle
10 Position Automatic Tool Changer
Ethernet Interface, usb port
High Speed Machining with Look-Ahead
Remote Jog Handle with LCD
24" Z-AXIS EXTENSION
RIGID TAPPING
coolant system
